Model
|
Max.
Flow
GPM
|
Max.
Head
FT
|
Max.
Temp
oF
|
Max.
Visc
SSU
|
Max.
Spec
Grav.
|
Connections
|
Wetted**
Materials
|
MOTOR DATA
|
Shp.
Wt.
Lbs
|
Overall
Dimensions
In.
|
|
Inlet
|
Outlet
|
HP
|
RPM
|
Volts
|
PH
|
Hz
|
Encl
|
|
XT200-200 W57
|
185
|
50
|
225
|
1500
|
1.1
|
3” FPT
|
2” FPT
|
CI, BR, CE, CB, BN, 3S
|
2
|
3600
|
230/460
|
3
|
60
|
ODP
|
76
|
17 x 10x 11
|
| XT200-300 Y57 |
220
|
65
|
225
|
1500
|
1.1
|
3” FPT
|
2” FPT
|
CI, BR, CE, CB, BN, 3S
|
3
|
3600
|
230/460
|
3
|
60
|
ODP
|
84
|
19 x 10x 10
|
| XT200-500 X57 |
260
|
100
|
225
|
1500
|
1.1
|
3” FPT
|
2” FPT
|
CI, BR, CE, CB, BN, 3S
|
5
|
3600
|
230/460
|
3
|
60
|
ODP
|
106
|
20 x 10x 11
|
|
XT200-750 G57
|
280
|
120
|
225
|
1500
|
1.1
|
3” FPT
|
2” FPT
|
CI, BR, CE, CB, BN, 3S
|
71/2
|
3600
|
230/460
|
3
|
60
|
ODP
|
113
|
23 x11x 12
|
|
Other seal configurations available for
temperatures up to 350°F.
* Contact a Water Cooling Engineer for assistance in selecting
pumps for fluids over 500 SSU.
** Also available in All Bronze and 316SSS construction.
See page 5 for material legend.
|
Contact a Water Cooling Application Engineer for assistance
in selecting pumps for fluids with specific gravity over 1.1.
Also available in TEFC and Explosion Proof.
|
|
