Model
|
Max.
Flow
GPM
|
Max.
Head
FT
|
Max.
Temp
oF
|
Max.
Visc
SSU
|
Max.
Spec
Grav.
|
Connections
|
Wetted**
Materials
|
MOTOR DATA
|
Shp.
Wt.
Lbs
|
Overall
Dimensions
In.
|
|
Inlet
|
Outlet
|
HP
|
RPM
|
Volts
|
PH
|
Hz
|
Encl
|
|
XT150-100 N57
|
110
|
60
|
225
|
1500
|
1.1
|
2” FPT
|
11/2” FPT
|
CI, BR, CE, CB, BN, 3S
|
1
|
3600
|
230/460
|
3
|
60
|
ODP
|
67
|
16 x 9x 10
|
| XT150-200 W57 |
120
|
80
|
225
|
1500
|
1.1
|
2” FPT
|
11/2” FPT
|
CI, BR, CE, CB, BN, 3S
|
2
|
3600
|
230/460
|
3
|
60
|
ODP
|
70
|
17 x 9x 10
|
| XT150-300 Y57 |
105
|
140
|
225
|
1500
|
1.1
|
2” FPT
|
11/2” FPT
|
CI, BR, CE, CB, BN, 3S
|
3
|
3600
|
230/460
|
3
|
60
|
ODP
|
78
|
19 x 9x 10
|
|
XT150-500 X57
|
170
|
140
|
225
|
1500
|
1.1
|
2” FPT
|
11/2” FPT
|
CI, BR, CE, CB, BN, 3S
|
5
|
3600
|
230/460
|
3
|
60
|
ODP
|
100
|
20 x 9x 10
|
|
XT150-750 G57
|
180
|
150
|
225
|
1500
|
1.1
|
2” FPT
|
11/2” FPT
|
CI, BR, CE, CB, BN, 3S
|
71/2
|
3600
|
230/460
|
3
|
60
|
ODP
|
107
|
21 x 9x 10
|
|
Other seal configurations available for
temperatures up to 350°F.
* Contact a Water Cooling Engineer for assistance in selecting
pumps for fluids over 500 SSU.
** Also available in All Bronze and 316SSS construction.
See page 5 for material legend.
|
Contact a Water Cooling Application Engineer for assistance
in selecting pumps for fluids with specific gravity over 1.1.
Also available in TEFC and Explosion Proof.
|
|
